Complete 3.3kW solar hybrid system for US homes. 110V split phase output, 48V battery ready, built-in MPPT charger, <10ms UPS backup. Perfect for home backup, RV, or off-grid cabin.
| Total System Power | 3.3kW |
| Solar Input | 90-450VDC, up to 4500W solar panels |
| Battery Storage | 25.6V (2-10kWh recommended), LiFePO₄ or lead-acid |
| Backup Time (with 5kWh battery) | 5-8 hours (essential loads) |
| What It Can Power | Fridge (1), LED lights (10+), TV (1), Computer (2), Fan (3) |
| Warranty | 5-10 years on system |
This is a complete 3.3kW solar hybrid system, not just an inverter. It’s designed for US homes, RVs, and off-grid cabins to run on solar power, store energy in batteries, and keep your lights on during blackouts.
| ⚡ 3.3kW single phase hybrid power station | converts solar to household power |
| ☀️ Built-in MPPT solar charger | connects directly to solar panels (90-450VDC) |
| 🔋 24V battery ready | works with LiFePO₄ or lead-acid batteries |
| 🔌 Native 110V-120V output | no transformer needed, plug and play |
| 🏠 Power your home | run fridge, lights, TV, computer, and small appliances |
| ⚡ Keep running during outages | <10ms UPS switch, seamless backup |
| ☀️ Save on electricity bills | use free solar energy, store excess for night use |
| 🔋 Go off-grid completely | disconnect from utility, live anywhere |
No need to buy separate charge controller, inverter, or transfer switch
110V outlets and 220V appliances, no transformer needed
Built-in MPPT charger, just add solar panels
Works with 48V LiFePO₄ or lead-acid batteries, BMS communication ready
<10ms automatic backup, keeps your family powered
IP65 weatherproof, install in garage, basement, or outside
| SYSTEM MODEL | Description | Specs/Quantity | Warranty |
| Solar panels | Solvic Topcon 600w | 4-5pcs | 30 Years |
| TOtal PV Input (kWh) | 3kWh | ||
| Required Roof area | 28-31m2 | ||
| Daily power generation (kWh) | Based on 5 Peaking H | 15kWh | |
| Solar hybrid inverter (KW) | Solvic 3.3kw | 1pc | 5 Years |
| AC output type | US standard | Single Phase | |
| AC output voltage | 110V 50/60HZ | ||
| Battery Bank (kWh) | Solvic 2.56kWh | 1-2pc | 5-10 Years |
| Battery Cycles(80%DoD) | LiFePo4, 6000+ | ||
| PV Combiner Box | Customized 1 in 1 out | 1set | 10 Years |
| PV Cables | 4mm2 DC PV Cables | 100m | 10 Years |
| Solar mounting Brackets | Roof/Ground installation | 1 set | 10 Years |
| System Delivery | Standard Wooden Box + Connection Drawing Guidance | ||
| System Expansion | System support parallel connection of 2 or more pcs | ||
| Certifications | IEC/EN61000-6-1/2/3/4,IEC/EN 62109-1,IEC/EN 62109-2, CE, MSDS, UN38.3 | ||
The system includes the hybrid power station (inverter, MPPT charger, and UPS transfer switch all in one). You will need to purchase solar panels and a 48V battery bank separately. Cables and mounting accessories are also sold separately. This gives you the flexibility to choose the panel and battery brands that fit your budget and needs.
3.3kW system can power essential home loads simultaneously: Refrigerator (1 unit) – 150-200W running LED lights (10-15 bulbs) – 100-150W TV (1-2 units) – 100-200W Laptops / computers (2-3) – 100-150W Fans (3-4) – 150-200W Router, modem, phone chargers – 50W *Total: approximately 600-900W continuous, well within the 3.3kW capacity. For 220V appliances like well pumps or dryers, check the starting surge requirement.*
Runtime depends on your battery bank size and load: With 5kWh battery (48V 100Ah): Approximately 5-8 hours for essential loads With 10kWh battery (48V 200Ah): Approximately 10-16 hours for essential loads With solar panels during the day: Unlimited as long as the sun is shining
