205W to 250W monocrystalline solar panel for 12V 24V RV off-grid system. Up to 21.08% efficiency. 5400Pa snow load. TUV certified. IP67 waterproof. MC4 ready
| 21.08% Peak Efficiency | Industry Leading for This Wattage |
| 12V 24V 48V Compatible | Works with Any Battery Bank |
| RV, Cabin, Marine, Off-Grid | One Panel Fits All |
| Certified for Hurricane & Blizzard | 2400Pa Wind / 5400Pa Snow |
| Anti-PID & Double EL Tested | No Hidden Defects |
| 90cm MC4 Cable Included | No Extra Parts to Buy |
Serious Power for Serious Off-Grid
A 250W solar panel is the workhorse of off-grid solar. Unlike smaller panels that require extensive wiring to reach useful power, these panels deliver substantial wattage in a single unit – perfect for RV roofs, cabin systems, marine applications, and home backup.
Available in 9 power options from 205W to 250W, with 12V, 24V, and 48V compatibility, you can build exactly the system your energy needs demand – from a single panel for weekend camping to a full array for year-round off-grid living.
Up to 21.08% module efficiency means more power from less roof space. Whether you’re mounting on a van, boat, or cabin, you get maximum harvest from every square inch.
Our 210mm split cell monocrystalline technology achieves 21.08% peak efficiency – significantly higher than standard 250W panels (typically 15-18%). This means:
More power in the same footprint
Fewer panels needed for your energy goals
Better low-light performance on cloudy days
Unlike basic panels limited to 12V, our series works with any battery bank voltage:
Single panel → 12V battery charging (Vmp 24-42V, works with MPPT controller)
Two panels in series → 24V system
Four panels in series → 48V system
| Parameter | 205W | 210W | 215W | 220W | 225W | 230W | 235W | 240W | 250W |
| Cell Size | 210mm | ||||||||
| Pmax (W) | 205 | 210 | 215 | 220 | 225 | 230 | 235 | 240 | 250 |
| Vmp (V) | 24.11 | 24.53 | 24.78 | 39.03 | 39.64 | 41.04 | 41.4 | 42.05 | 40.24 |
| Imp (A) | 8.5 | 8.56 | 8.68 | 5.64 | 5.68 | 5.6 | 5.68 | 5.71 | 6.22 |
| Voc (V) | 28.36 | 28.56 | 28.85 | 46.19 | 46.92 | 48.63 | 49.05 | 49.76 | 46.96 |
| Isc (A) | 8.95 | 9.01 | 9.13 | 5.97 | 6.01 | 5.94 | 6.02 | 6.05 | 6.57 |
| Efficiency (%) | 19.86 | 20.35 | 20.83 | 19.69 | 20.13 | 19.36 | 19.78 | 20.2 | 18.82 |
| Dimensions (mm) | 1545×668 | 1545×668 | 1545×668 | 1270×880 | 1270×880 | 1350×880 | 1350×880 | 1350×880 | 1725×770 |
| Weight (kg) | 10.83 | 10.83 | 10.83 | 11.73 | 11.73 | 12.48 | 12.48 | 12.48 | 13.95 |
| Max System V | 1500V | ||||||||
| Max Fuse | 10A | 10A | 10A | 10A | 10A | 10A | 10A | 10A | 15A |
Charge Controller
Controller Type Sizing for 250W Panel Efficiency Best For
PWM 20-30A 75-80% Budget builds, 12V only
MPPT 30-40A 95-98% Maximum harvest, 12V-48V
Recommendation: MPPT controllers provide 20-30% more power from the same panel – pays for itself within 1-2 years.
Battery Bank Sizing
Battery Type Capacity for 250W Panel Usable Cost
AGM 200-300Ah (at 12V) ~50% $
LiFePO4 100-150Ah (at 12V) 80-90% $$
Inverter (for AC loads)
Basic (laptop, TV, lights): 300-600W
Power tools, small appliances: 1,000-1,500W
Full cabin: 2,000-3,000W
| Mounting Options | Mount Type Best For | Difficulty |
| Roof mount | RVs, vans, cabins | Moderate |
| Ground mount | Homes, cabins, farms | Easy |
| Pole mount | Off-grid, farms | Moderate |
| Portable | Camping, temporary | Very easy |
8KW Split Phase Hybrid Inverter – 48V to 120/240V UL Certified with 500V MPPT for Solar System
Solvic 3.3KW/6.3KW 120V Hybrid Solar Inverter | 500V PV Input | UL Certified for US & Latin America
Solvic 1000W-6000W Low Frequency Split Phase Inverter – 12V/24V/48V to 120/240V, Single or Split Phase Selectable, 3x Surge for Motor Start
Yes. We specialize in custom size solar panels for volume orders. Contact us with your required: Wattage (any between 50W-400W) Dimensions Voltage Cable length and connector type Logo printing on frame or backsheet
Yes – that's exactly what they're designed for. Two 250W panels in series (Vmp ~80V) perfectly charges a 24V battery bank. Four in series charges 48V. Use an MPPT controller rated for the higher input voltage (150V or 250V models).
10-year materials and workmanship warranty – covers manufacturing defects, frame corrosion, junction box issues. 25-year linear power output warranty – guarantees ≥80% of rated power at year 25. Annual degradation ≤0.8%.
