The SAJ H2 Low Voltage Split Phase Hybrid Inverter is specifically engineered for North American residential solar storage systems, delivering 120/240V split phase output across a power range of 5kW to 11.4kW.
| Output Power | 5-11.4kW (5/7.6/9.6/11.4k) |
| Output Voltage | 120/240V Split Phase |
| MPPT Voltage Range | 90-550V |
| Battery Voltage | 48V (40-60V) |
| UPS Transfer Time | ≤20ms / ≤10ms |
| Enclosure Rating | IP65 / NEMA 4X |
The SAJ H2 Low Voltage Split Phase Hybrid Inverter provides reliable whole-home backup power with output up to 11.4 kW and an integrated 200A transfer relay,enabling the entire home to remain powered during grid outages without requiring a separate critical loads sub-panel.The IP65-rated enclosure supports both indoor and outdoor installation, and the inverter is compatible with both lithium and lead-acid batteries for flexible and cost-effective energy storage
US residential solar storage systems (120/240V split-phase)
Whole-home backup power solutions
Grid-tied and off-grid energy management
Homes with existing lithium or lead-acid batteries
Features an integrated 200A transfer relay and delivers up to 11.4kW of output power,providing whole-home backup without the need for an external sub-pane
Built-in UPS functionality enables switching times of ≤20ms when transitioning to battery power during a grid outage,ensuring uninterrupted operation for critical household loads
Equipped with up to 4 independent MPPT trackers (3 for 5/7.6kW models, 4 for 9.6/11.4kW models) to optimize PV energy capture and maximize system efficiency
IP65-rated protection allows for both indoor and outdoor installation.Compatible with both lithium and lead-acid batteries, offering flexible and cost-effective energy storage options
Supports generator input as a backup charging source,extending system runtime during prolonged grid outages or periods of low solar irradiation
Supports intelligent energy management through real-time monitoring,smart working modes,and app connectivity for enhanced control over home energy consumption
