650W N-Type TOPCon bifacial solar panel with 23.25% efficiency. 210mm 132 half-cells, 30-year warranty, 5400Pa load. For utility solar farm & commercial rooftop
| Dimensions | 2384 × 1134 × 30 mm |
| Weight | 33.5 kg (74 lbs) |
| Cell | 210mm N-Type TOPCon, 132 Half-Cells |
| Certifications | IEC61215, IEC61730, TUV, CE, ISO |
| Warranty | 30-Year Linear Power, 12-Year Product |
| Packaging | 36 pcs/pallet, 720 pcs/40HQ |
85% bifaciality with 210mm G12 wafers. Capture reflected light from ground, white roofs, or trackers.
Reduce modules per MW by ~15% vs 550W panels. Save on racks, cables, clips, and labor.
-0.30%/°C temp coefficient. Outperform PERC in high-temperature regions (Middle East, LATAM, US South).
30-year linear power warranty. Annual degradation <0.4%. Maximize IRR for long-term projects.
Imp ~17.0A – perfect for mainstream 1500V string inverters. No de-rating or special config needed.
TUV, IEC61215, IEC61730, CE, ISO. Passed salt mist, ammonia, sand & dust tests.
The sweet spot of power, size & bankability.
Unlike entry-level 550W PERC panels, our 630-650W TOPCon series uses 210mm N-Type wafers with 132 half-cells (G12-66) – the new standard for utility and large C&I projects.
Mature supply chain, stable production, widely compatible with mounting systems and trackers.
Generate more energy per square meter, ideal for land-constrained projects and high-value rooftops.
N-Type TOPCon eliminates LID (Light Induced Degradation). Lower annual degradation means more kWh delivered over 30 years.
1500V system voltage and 17.0A Imp match perfectly with leading inverter brands (Sungrow, SMA, Huawei). No need for double stringing or oversizing.
| Parameter | 630W | 635W | 640W | 645W | 650W |
| Cell Type | N-Type TOPCon, 182×210mm (G12R), 132 Half-Cells | ||||
| Pmax (W) | 630 | 635 | 640 | 645 | 650 |
| Module Efficiency | 22.80% | 23.00% | 23.10% | 23.20% | 23.25% |
| Vmp (V) | 42.2 | 42.4 | 42.6 | 42.8 | 43 |
| Imp (A) | 14.93 | 14.98 | 15.03 | 15.08 | 15.12 |
| Voc (V) | 50.5 | 50.7 | 50.9 | 51.1 | 51.3 |
| Isc (A) | 15.8 | 15.85 | 15.9 | 15.95 | 16 |
| Bifaciality | 85% | 85% | 85% | 85% | 85% |
| Dimensions | 2382×1134×30mm | ||||
| Weight | 35.0 kg (77 lbs) | ||||
| Temp Coefficient (Pmax) | #NAME? | ||||
| Max System Voltage | 1500V DC | ||||
| Max Series Fuse | 25A | ||||
| Certifications | IEC61215, IEC61730, TUV, CE | ||||
| Warranty | 30-year linear power / 12-year product | ||||
| *STC: Irradiance 1000W/m², Cell Temperature 25°C, AM1.5* | |||||
Solvic-620-640w-Bifacial-Solar-Module-Datasheet
G12R uses rectangular wafers (182×210mm) instead of square 210mm wafers. The 2382×1134mm size is narrower than standard G12 (2384×1303mm), making it easier to handle, cheaper to ship (more panels per container), and compatible with 1134mm-wide racking systems used for 182mm modules. Same power output, narrower profile.
1500V string inverters with per-string current >20A (Sungrow, SMA, Huawei). The ~15A Imp allows 2-3 strings per MPPT. The narrower 1134mm width also fits standard 1500V racking without modification.
IEC 61215 (performance) IEC 61730 (safety) TUV (third-party validated) CE (European compliance) PID resistant (96 hours, 85% RH) Salt mist (IEC 61701 – coastal) Ammonia (IEC 62716 – agricultural) Sand & dust (desert environments)
