Designed with up to 4 MPPT trackers and a DC/AC ratio up to 2.0, the MIN TL-XH-US series delivers exceptional solar harvest efficiency of up to 98.5% .
| Max. DC Input Voltage | 600V |
| Number of MPPT Trackers | 2 (3000–5000W models) / 3 (6000–7600W models) |
| Max. Input Current per MPPT | 13.5A |
| AC Voltage | 208V / 240V (split-phase) |
| Max. Output Current | 12.5A / 16A / 21A / 25A / 32A |
| Enclosure Rating | NEMA 4X (IP65) |
The Growatt MIN 3000-11400TL-XH-US series is a battery-ready, single-phase hybrid inverter engineered specifically for U.S. residential solar storage applications.Available in power ratings from 3kW to 11.4kW, this versatile inverter supports both DC-coupled and AC-coupled systems,enabling whole-home backup during grid outages with dark start capability to restart the system without utility power.
The built-in EMS supports multiple operation modes—Self-Consumption,Zero Export, Time-of-Use (ToU),and Off-Grid—allowing homeowners to maximize PV self-consumption and reduce electricity bills.With an IP65/NEMA 4X enclosure for outdoor durability,and real-time monitoring via the ShinePhone App,the Growatt MIN series offers a smart,reliable, and scalable energy management solution for modern American homes.
Supports full or partial home backup power with dark start capability, enabling system restart during grid outages without utility support. Works with ATS-US for seamless transition and uninterrupted power for critical loads
Configured with 2,3,or 4 independent MPPT trackers depending on model, maximizing energy harvest from complex rooftop orientations. The 2.0 DC/AC ratio allows flexible PV oversizing for higher yields during low-light conditions
Integrated EMS supports four operation modes—Self-Consumption, Zero Export, Time-of-Use (ToU), and Off-Grid—enabling homeowners to maximize solar self-consumption, reduce electricity bills, and adapt to dynamic tariff rates through real-time remote monitoring
Built-in Arc-Fault Circuit Interrupter (AFCI) detects and interrupts dangerous arc faults, while Rapid Shutdown Device (RSD) ensures fast PV array deactivation for firefighter safety. IP65/NEMA 4X outdoor-rated enclosure provides protection against dust and water
Compatible with Growatt ARO HV and LG Prime (Gen3) high-voltage batteries, supporting both DC-coupled and AC-coupled configurations. Scalable storage up to 4 modules per inverter (9.9kWh each) and parallel capability for expanded capacity
Compliant with UL1741SA/SB, IEEE1547, CA Rule 21, and HECO standards for seamless U.S. grid integration.Backed by a standard 10-year warranty with optional 15/20-year extensions for long-term peace of mind
