This versatile inverter supports both DC-coupled and AC-coupled system configurations, enabling whole-home backup power with dark start capability—the ability to restart the system during a grid outage without utility support.
| Number of MPPT Trackers | 4 |
| PV Strings per MPPT | 2 |
| AC Nominal Power (240V) | 8.2kW / 9.0kW / 10.0kW / 11.4kW |
| AC Voltage | 208V / 240V (split-phase) |
| Max. Efficiency | 98.3% – 98.5% |
| Enclosure Rating | NEMA 4X (IP65) |
Designed with 4 independent MPPT trackers and a 2.0 DC/AC ratio, the MIN TL-XH-US series delivers exceptional energy harvest with maximum efficiency up to 98.5%.
The built-in energy management system supports multiple operation modes—Self-Consumption, Zero Export, Time-of-Use (ToU), and Off-Grid—allowing homeowners to maximize PV self-consumption and reduce electricity bills. With an IP65/NEMA 4X enclosure for outdoor durability, 10-year warranty, and real-time monitoring via the ShinePhone App, the Growatt MIN series offers a smart, reliable, and scalable energy management solution for modern American homes.
Provides full or partial home backup power during outages. Dark start enables system restart without grid power
Maximizes solar harvest from complex roof layouts with flexible PV oversizing for higher low-light yields
Supports Self-Consumption, Zero Export, ToU, and Off-Grid modes via the ShinePhone App for optimal energy savings
Compatible with Growatt ARO HV and LG Prime batteries, supporting both DC-coupled and AC-coupled systems
Certified to UL1741SA, IEEE1547, CA Rule 21, and HECO standards. Backed by a 10-year warranty with optional extensions
Integrated arc fault detection and rapid shutdown ensure fire safety. IP65/NEMA 4X enclosure protects against dust and water
